Beatle Studio SecretsOur friends at Capitol Records gave Epiphone a news scoop and told us that The Beatles collected Mono LPs will be out early next year and as of now, they will just be released as a box set. Capitol also revealed some of the secrets behind the process to put the remastered catalog on vinyl:

The first stage in transferring the sound of a master recording to vinyl is the creation of a disc to be used during vinyl manufacture. There were two options to consider. A Direct Metal Master (DMM), developed in the late seventies, allows sound to be cut directly into a stainless steel disc coated with a hard copper alloy. The older, alternative method is to cut the sound into the soft lacquer coating on a nickel disc - the first of several steps leading to the production of a stamper to press the vinyl.

A 'blind' listening test was arranged to choose between a 'lacquer' or 'copper' cut. Using both methods, A Hard Day's Night was pressed with ten seconds of silence at the beginning and end of each side. This allowed not only the reproduction of the music to be assessed, but also the noise made by the vinyl itself. After much discussion, two factors swung the decision towards using the lacquer process. First, it was judged to create a warmer sound than a DMM. Secondly, there was a practical advantage of having 'blank' discs of a consistent quality when cutting lacquers.

The next step was to use the Neumann VMS80 cutting lathe at Abbey Road. Following thorough mechanical and electrical tests to ensure it was operating in peak condition, engineer Sean Magee cut the LPs in chronological release order.

He used the original 24-bit remasters rather than the 16-bit versions that were required for CD production. It was also decided to use the remasters that had not undergone 'limiting' - a procedure to increase the sound level, which is deemed necessary for most current pop CDs.

Beatle Studio SecretsHaving made initial test cuts, Magee pinpointed any sound problems that can occur during playback of vinyl records. To rectify them, changes were made to the remasters with a Digital Audio Workstation. For example, each vinyl album was listened to for any 'sibilant episodes' - vocal distortion that can occur on consonant sounds such as S and T. These were corrected by reducing the level in the very small portion of sound causing the undesired effect.

Similarly, any likelihood of 'inner-groove distortion' was addressed. As the stylus approaches the centre of the record, it is liable to track the groove less accurately. This can affect the high-middle frequencies, producing a 'mushy' sound particularly noticeable on vocals. Using what Magee has described as 'surgical EQ,' problem frequencies were identified and reduced in level to compensate for this.

Beatle Studio SecretsThe last phase of the vinyl mastering process began with the arrival of the first batches of test pressings made from master lacquers that had been sent to the two pressing plant factories. Stringent quality tests identified any noise or click appearing on more than one test pressing in the same place. If this happened, it was clear that the undesired sounds had been introduced either during the cutting or the pressing stage and so the test records were rejected. In the quest to achieve the highest quality possible, the Abbey Road team worked closely with the pressing factories and the manufacturers of the lacquer and cutting styli. An additional and unusual challenge was to ensure the proper playback of the sounds embedded in the 'lock-groove' at the end of side two of Sgt. Pepper's Lonely Hearts Club Band.

Requiring a combination of good timing and luck, it had always been a lengthy and costly process to make it work properly. In fact, it was so tricky, it had never been attempted for American pressings of the LP. Naturally, Sean Magee and the team perfected this and the garbled message is heard as originally intended on the remastered Sgt. Pepper LP.

And if that's not enough Beatle news for you in one day, the remastered version of Magical Mystery Tour is out and there's a new website, too.
